  3. Calculation of the dosage of rebar anchoring adhesive

Calculation of the dosage of rebar anchoring adhesive

According to the 10 years experience of post installed anchoring, there is a formula for the amount of HM-500 injectable anchoring adhesive​:

rebar anchoring adhesive

According to the 10 years experience of post installed anchoring, there is a formula for the amount of HM-500 injectable anchoring adhesive:

W=2/3*π*（D/2）2*L

It can be added to the workers' Consumption: 5-15%


W: amount of anchoring glue used for each anchor hole

D: hole diameter

L:hole depth

(Each anchoring adhesive is calculated by 390ML, and the specific gravity is 1.4-1.6 g/cm3 )


The table of using gule quantities of HM-500 epoxy anchor adhesive


the steel

bar diameter

pore

size

pore

depth

the injecting

glue volume

theoretic

number

note
mmmmmmml(2/3v)piece
8
12806.0364.6710d
8121209.0443.1415d
81216012.0632.3320d
101410010.2638.0110d
101415015.0825.8615d
101420020.5219.0120d
121612016.0924.2310d
121618024.1216.1615d
121624032.1812.1120d
141814023.7316.4310d
141821035.6110.9515d
141828047.46832120d
162216040.529.6210d
162224060.796.4115d
162232081.044.8120d
182518058.876.6210d
182527088.314.4115d
1825360117.743.3120d
202820082.064.7510d
2028300123.093.1615d
2028400164.122.3720d
2230220103.623.7610d
2230330155.432.515d
2230440207.241.8820d
2532250133.972.9110d
2532375200.961.9415d
2532500267.951.4520d
